Model: DS-30
Type: Vertical Slotter
Year: New
SPECIFICATIONS:
Stroke……………….. 30”
Longitudinal Travel..(X).. 26”
Cross Travel………(Y).. 20”
Table Diameter………… 36”
Motor Size……………. 7.5 HP – 220/440V – 3 Phs
Weight……………….. 9040 Lbs
Dimensions……………. To be Advised
EQUIPPED WITH:
Diving Head
Rotary Table
Stroke Adjustment
Vee-Belt Guards
(1) Railing Set For Electric Motor
Oil Lubrication System
MACHINE FEATURES:
Rigid Construction
Quick Return Movement
Rocker Arm Mechanism Operated
Gears In Gear Box Hardened
Ground Shafts
OPTIONAL ACCESSORIES:
12” Thru Chuck w/Plate
(4) Safety Bellows
(1) Set of Lighting
Wooden Box Packing
