Model: ARS-3 … HPK-60
Type: Single Pinch
Year: New
SPECIFICATIONS:
Shaft Diameter……. 2-3/8”
Roll Diameter…….. 8.46”
Driven Rolls……… 3
Rolling Speed (VS)… 13 FPM
Work Plane……….. Horizontal / Vertical
Adjustable Rolls….. 3
Motor……………. 2 HP – 220/440V – 3 Phs
Weight…………… 1900 Lbs
CAPICATIES:
Flats Hard……….. 3-1/8” x 5/8” x 32” Dia
Flats Easy……….. 4-3/4” x 1” x 24” Dia
Square Bar……….. 2” x 32” Dia
Angle Out………… 3” x 3” x 1/4” x 40” Dia
Angle In…………. 3” x 3” x 1/4” x 48” Dia
Tee Out………….. 3-1/8” x 3/8” x 40” Dia
Tee In…………… 3-1/8” x 3/8” x 48” Dia
Channel Out………. 4-3/4” x 32” Dia
Channel In……….. 4-3/4” x 48” Dia
Round Bar………… 2” x 32” Dia
Pipe Sch. 40……… 3” x 63” Dia
Tubing Round……… 4” x 14 Ga x 63”Dia
Tubing Square…….. 2-3/4” x 2-3/4” x 1/8” x 56” Dia
Tubing Rectangle….. 3-1/8” x 1-1/2” x 1/8” x 56” Dia
EQUIPPED WITH:
Dual Foot Control
Emergency Stop
Cabinet Base w/Door
Set of Universal Tooling
MACHINE FEATURES:
Single Pinch
H & G Shafts & Gears
Horizontal/Vertical
Rugged Steel Frame
(3) Driven Rolls
Hydraulic Adjustment of Top Roll
Manual Adjustment Of Guide Rolls
OPTIONAL ACCESSORIES:
Variable Speed – 1 Phs
COMMENTS:
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need a Part ?
Have a Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
