Model: 2680-C
Type: Geared Head
Year: New
SPECIFICATIONS:
Headstock……………. Geared Head
Swing Over Bed……….. 26”
Swing Over Cross Slide… 17.24”
Swing in Gap…………. 35”
Dist Between Centers….. 80”
Max Turning Length……. 80”
Spindle Nose…………. D1-8
Spindle Hole…………. 3-1/8”
Bed Width……………. 15.75”
Spindle Speeds(12)……. 15 – 1500 RPM
Threading……………. Inch/Metric
Motor Size…………… 15 HP – 220/440V – 3 Phs
Tailstock Taper………. #5 MT
Gross Weight…………. 6550 Lbs
Dimensions…………… 137″(l) x 41″(w) x 52″(h)
EQUIPPED WITH:
14″ – 4 Jaw Chuck
(4) Way Toolpost
Coolant System
Splash Guard & Chuck Guard
(3/4″ – 9″) Steady Rest
20″ Face Plate
(4) Way Carriage Stop
Tailstock
Halogen Work Light
Tool Kit & Manuals
MACHINE FEATURES:
3-1/8″ Spindle Hole
Gap Bed Design
Quick Change Gear Box
H & G Headstock Gears
H & G Bedways
(1) Piece Cast Meehanite Bed
OPTIONAL ACCESSORIES:
10″ – 3 Jaw Bison Chuck
12″ – 3 Jaw Bison Chuck
16″ – 3 Jaw Bison Chuck
16″ – 4 Jaw Bison Chuck
Follow Rest
Micrometer Carriage Stop
Taper Attachment
15″ Steady Rest
19.5″ Steady Rest
5C Collet Set (1/8″ – 1-1/8″ x 1-16″)
5C Collet Closer
Aloris Quick Change Toolpost w/(7) Holders
14N Jacobs “Ball Bearing” Chuck w/Arbor (0 – 1/2″ Capacity)
Newall Digital Readout
