Model: B-25-2 … Semi Automatic
Type: Double Column
Year: New
SPECIFICATIONS:
Cutting Capacity:
Round
Max. Height….. 25-1/2”
At 90 Degrees… 25-1/2”
At 45 Degrees… 24”
Rectangle
Max. Width…… 40”
At 90 Degrees… 25” x 40”
At 45 Degrees… 25” x 24”
Blade Size:………. 1-1/2” x .042” x 270”
Blade Speed(V.S.)…. 60-500 FPM
Motor Size:………. 10HP – 230V – 3 Phs
Weight:………….. 6600 Lbs
EQUIPPED WITH:
Double Column
Semi-Automatic
Full Stroke Hydraulic Vises
Adjustable Vise Pressure
Swivel Vise (45 Degree)
Carbide Blade Guides
Adjustable Hydraulic Downfeed(0-500 LBS)
Hydraulic Blade Tension
Flood Coolant System
Variable Blade Speeds
Full Guarding
Hydraulic Vise & Manual 45 Degrees Swivel
Hydraulic Blade Tension w/Indicator
Blade Break/Stall Switch
Hydraulic Positioned Guide Arms
Operator Manual & Parts List
OPTIONAL ACCESSORIES AVAILABLE … P.O.R.
Hydraulic Hold Down, Saw Vise
Hydraulic Chip Conveyor
Outboard Vise
Outboard Vise w/Hydraulic Hold Down
40” X 56” Discharge Table w/Stock Stop
High Speed Drive & Guides (500-3000 SFPM)
40” x 5’ Manual Conveyor
40” X 10’ Manual Conveyor
40” X 10’ Hydraulic Powered Conveyor
COMMENTS: Mfg. In U.S.A.
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need A Part ?
Have A Technical Question ?
CALL: IMCO At 614-914-5087
F.O.B.: Columbus, Ohio
TERMS: Check w/Order
All prices subject to change with notice
