Model: KL-2480
Spindle Hole: 3-3/8″
Year: New
Type: Flat Bed
SPECIFICATIONS:
Swing Over Bed……….. 24″
Swing Over Cross Slide… 13.5″
Dist Between Centers….. 80″
Max. Turning Length…… 72.8″
Spindle Nose…………. D1-8
Spindle Hole…………. 3-3/8 (4″ Option)
Bed Width……………. 13.78″
Spindle Ranges……….. 3
Spindle Speeds(VS)……. 25 – 2000 RPM
Tailstock Taper………. #5 MT
Rapid Traverse……….. 270/180 IPM
Motor Size…………… 10 HP – 220V – 3 Phs
Control Type…………. Centroid T-400i
Weight………………. 7700 Lbs
Dimensions…………… 136″(l) x 74″(w) x 77″(h)
EQUIPPED WITH
Centroid T-400i CNC Control
“Conversational”
“G” Code
15” Color Monitor
RS-232 & Ethernet Ports
(1) GB Solid State Hard Drive
Shop Floor Programming(Conversational)
Totally Enclosed (Sliding Door)
Safety Chuck Guard
Automatic Lube System
Coolant System
Back Plate
Halogen Work Light
Tool Box w/Tools
Leveling Bolts & Plate
Operations Manual
MACHINE FEATURES
“Flat Bed” Design … “H & G” Ways
(8) Position Turret
“Dual” Hand Wheels for Manual Operation
“Laser” Tested Accuracy
“T-Slotted” Cross Slide
H & G Precision Ballscrews & Bedways
Massive Meehanite Casting … (1) Piece Construction
(3) Speed Geared Headstock – Automatic Shift
Tailstock (Manual)
OPTIONAL ACCESSORIES AVAILABLE … P.O.R.
10” – 3 Jaw Chuck
12” – 3 Jaw Chuck
12” – 4 Jaw Chuck
8” – 3 Jaw Hydraulic Chuck (2” Hole)
12” – 3 Jaw Chuck (4.05” Hole)
16” – 3 Jaw Chuck (5.34” Hole)
12” – 3 Jaw “Hydraulic” Chuck (4” Hole)
16” – 4 Jaw Chuck (3.93” Hole) w/Adaptor Plate
20” – 4 Jaw Chuck (4.92” Hole) w/Adaptor Plate
Upgrade to 4” Spindle Hole & 15 HP
(4) Way Electric Tool Post
Quick Change Tool Post w/(4) Holders
(8) Station “Automatic” Electric Turret (1” Tool)
(2.3” – 11”) Steady Rest (Roller Type)
(1.20”-9.8”) Follow Rest
Transformer (480V to 220V)
Rigid Tapping
Additional Centroid Control Manual
Installation & Set-Up
Control Training
COMMENTS: Control Mfg. In U.S.A.
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER:
Need a Part ?
Have a Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
Terms: Check w/Order
