Model: RL-2440-NC… Centroid T-400i Control
Spindle Hole: 3-3/8″
Year: New
Type: Flat Bed
SPECIFICATIONS:
Swing Over Bed:………….. 24”
Swing Over Cross Slide:…… 13”
Cross Slide Travel:………. 11.5″
Facing Diameter “Maximun”:… 22″
Dist Between Centers:…….. 40”
Max. Turning Length:……… 31.5”
Spindle Nose:……………. D1-8
Spindle Hole:……………. 3-3/8”
Bed Width:………………. 13.78”
Spindle Speeds(VS)……….. 27 – 2200 RPM
Spindle Ranges:………….. (3) Automatic
Tailstock Taper:…………. #5 MT
Rapid Traverse:………….. Yes
Motor Size:……………… 10 HP – 220V – 3 Phs
Control Type:……………. Centroid T-400i
Weight:…………………. 7000 Lbs
Dimensions………………. To be Advised
EQUIPPED WITH:
15″ – 3 Jaw Chuck (Manual)
Centroid T-400-S Control
Conversational Programming
G-Code (Fanuc Style) Programming
Digitizing Package W/Software
RS-232 & Ethernet Ports
(1) GB Solid State Hard Drive
USB 2.0
Dual Hand Wheels For Manual Operation
Full Enclosure
Work Light
Coolant System
Auto Lube
Way Covers
Chip Tray
Tools & Tool Box
H & G Bed Way
Slotted – Rear Cross Slide
Quick Change Toolpost
OPTIONAL ACCESSORIES AVAILABLE … (P.O.R.)
Installation & Set-Up $ 950 … Per Day Plus Expenses
Control Training “No Charge” (On IMCO’s Showroom Floor)
COMMENTS: Centroid T-400i CNC Control Mfg. in USA !
“U.S.A.” Importer – Distribution & Parts Center:
Need A Part ?
Have A Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
