Model: F-16-1A-CNC
Year: New
Type: Hydraulic /Double Column
SPECIFICATIONS:
Cutting Capacity:
Rounds
Max Height…… 16″
At 90 Degrees… 16″
Rectangles
Max Weight…… 18″
At 90 Degrees… 16″ x 18″
Blade Speed (VS)…… 60 – 425 SFPM
Blade Size………… 1-1/4″ x .042″ – 15′
Work Height……….. 35″
Motor Size………… 7.5 HP-208/460V-3 Phs
Weight……………. 3250 Lbs
EQUIPPED WITH
Fully Automatic
CNC Bar Feed 0”-25”
Digital Membrane Screen Controls
(99) Plus Job Selection
Machine Diagnostics
Automatic Keft Compensation
Up To 500” Part Length
Variable Blade Speed
Manual Blade Tension w/Indicator
Variable Vise Pressure
Out Of Shut Off
1-1/4” Bi-Metal Blade
Built In Coolant System
Blade Brake / Stall Switch
OPTIONAL ACCESSORIES AVAILABLE … P.O.R.
Air Hold Down Saw & Bar Feed Vise
Electronic Chip Conveyor (Auger Style)
20” x 48” Discharge Work Table
Work Light
High Speed (1” Blade) 400 – 3000 SFPM
6” Centers – Free Standing Roller Stock Conveyor
18” x 5’ x 2500 LBS Capacity
18” x 10’ x 5000 LBS Capacity
21” x 5’ x 2500 LBS Capacity
21” x 10’ x 5000 LBS Capacity
COMMENTS: Mfg. In U.S.A.
