Model: 52-A
Type: Air
Year: New
SPECIFICATIONS:
Length of Cut………… 52-1/4”
Max. Thickness of Cut…. 16 ga
Strokes per Minute……. 40 SPM
Maximum PSI………….. 75 PSI
Back Gauge Range……… 30″
Front Gauge Range…….. 37″
Weight………………. 1085 Lbs
Dimensions (LxWxH)……. 61″ x 25″ x 42″
CAPACITIES:
Mild Steel ………….. 16 ga
Stainless …………… 20 ga
Aluminum ………….. 12 ga
EQUIPPED WITH:
Foot Operated Air Valve Control
Pressure Regulator
Air Gaige
Oiler/Condenser Cups & Neoprene
Hi Chrome … Hi Carbon … (4) Edge Blades
Padded Holddown
Double Locking Back Gauge w/ Scales and Vernier Wheels
Frame, Bed & Head Constructed of Heavy Duty Cast Iron
OPTIONAL ACCESSORIES (P.O.R.):
4′ Squaring Arm
Hi-Carbon … Hi-Chrome Blades
COMMENTS: Mfg. in The U.S.A.
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need A Part?
Have A Technical Question?
CALL: IMCO at 614 464-4376
F.O.B.: Location
TERMS: Check w/Order
All Prices subject to change without notice
