Model: 1318 … Variable Speed
Type: Scissor … Manual
Year:
SPECIFICATIONS:
Cutting Capacity
Rounds
(Max. Height)… 13”
at 90 Degrees… 13”
at 45 Degrees… 11-1/2”
Rectangles
(Max. Width)…. 18”
at 90 Degrees… 13” x 18”
at 45 Degrees… 11” x 9-1/2”
Blade Size:……….. 1” x .035” x 12’ 6”
Blade Speed(VS)……. 70 – 375 SFPM
Motor Size:……….. 2 HP-115V-1Phs
Weight:…………… 955 Lbs
EQUIPPED WITH:
(2) Extra Blades
Variable Hydraulic Feed
Combination Reduction Gearbox & Perimeter
Ring Gear Blade Drive
Infinitely Variable Blade Speed
Overload & Under Voltage Protection
Auto Shut Off – End of Cut
OSHA Blade Guarding
45 Degree Swivel Visel
Coolant System w/Coolant
Powered Blade Brush
Adjustable Stock Stop
OPTIONAL ACCESSORIES AVAILABLE … (P.O.R.)
15″ Wide Roller “Mid Duty” (250#) Stock Stand
6″ Wide Roller “Heavy Duty” (1000#) Stock Stand
12″ Wide Roller “Heavy Duty” (1000#) Stock Stand
5’ x 18″ Roller Conveyor
5’ x 24″ Roller Conveyor
10’ x 18″ Roller Conveyor
10’ x 24″ Roller Conveyor
COMMENTS: Mfg. in U.S.A.
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need A Part ?
Have A Technical Question ?
CALL: Machinery Connection at 614-914-5087
F.O.B.: Columbus, Ohio
TERMS: Check w/Order
All prices subject to change without notice
