Model : 1018-S
Type: Scissors – Manual
Year: New
SPECIFICATIONS:
Cutting Capacity:
Rounds:
Max. Height…. 10”
at 90 Degree… 10”
at 45 Degree… 6” (L)
Rectangle:
Max. Width….. 18”
at 90 Degree… 10” x 18”
at 45 Degree… 10” x 9” (L)
Blade Size:………. 10’2” x 1”
Blade Speed (4)…… 114 – 377 FPM
Motor Size:………. 2 HP – 220V – 1 Phs (Only)
Weight:………….. 750 Lbs
EQUIPPED WITH:
“H & G” Worm Gears
Automatic Shut Off
45 Degree Swivel Vise
Down Feed … Variable Hydraulic Control
(1) Carbon Blade
Blade Chip Brush Safe Guards
Blade Tension Adjustment
COMMENTS:
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need a Part ?
Have a Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
