Model: LM-810-R
Type: Electro/Mechanical
Year: New
SPECIFICATIONS:
Length of Cut………… 97”
Max. Thickness of Cut…. 10 ga
Strokes per Minute……. 35 SPM
Motor Size…………… 10 HP – 220V or 440V – 3 Phs
Weight………………. 7000 Lbs
Dimensions (LxWxH)……. 116″ x 72″ x 565″
CAPACITIES:
Mild Steel ………….. 10 ga
Stainless …………… 14 ga
Aluminum ………….. 3/16”
EQUIPPED WITH:
Performance Package Consisting of:
5’ Squaring Arm w/Adjustable Stop
(2) Front Support Arms
Air Operated Sheet Support System
(R = Rear)
Independent Self-Leveling Hold Down Feet
Motor Reverse Control
Adjustable Guide Blocks
Remote Foot Pedal Control
Hi Chrome…Hi Carbon…(4) Edge Blades
Precision – Machined Table
Dual Inlaid Bed Scales – Inch/Metric
Non – Metallic Gibs
Neoprene Hold Downs Inserts (Prevents Marring)
“2x-F” Front Operated Manual Back Gauge
w/Pointer & Scale (Allows Full Back Gauge
Travel w/(2) Full Revolutions of the Handle)
MACHINE FEATURES:
Precision – Machined Table
Dual Inlaid Bed Scales – Inch/Metric
Non – Metallic Gibs
Neoprene Hold Downs Inserts (Prevents Marring)
“2x-F” Front Operated Manual Back Gauge
w/Pointer & Scale (Allows Full Back Gauge
Travel w/(2) Full Revolutions of the Handle
OPTIONAL ACCESSORIES (P.O.R.):
Digital Backgague Readout
Flip-Stops for Squaring Arm
Front Support Arms (Pair)
T-Slotted Table w/(2) Front Support Arms &
Inlaid Inch/Metric Scales
Additional Fip-Up Stops for T-Slotted Support
Arms & Table
30″ Power “Go-To” Backgauge
Protractor Attachment
Stroke Counter (Electro-Mechanical)
Work Shadow Light
5′ Squaring Arm w/Inlaid Inch/Metric Scale
10′ Squaring Arm w/Inlaid Inch/Metric Scale
Hi-Carbon … Hi-Chrome (4) Edge Blades
COMMENTS: Mfg in the U.S.A.
“USA” IMPORTER – DISTRIBUTION & PARTS CENTER
Need A Part ?
Have A Technical Question ?
CALL: IMCO at 614-914-5087
F.O.B.: Location
TERMS: Check w/Order
All prices subject to change without notice
