Model: CP-30-E
Type: Single Pinch
Year: New
SPECIFICATIONS:
Shaft Diameter:…….. 1-3/16”
Roll Diameter:……… 5”
Driven Rolls:………. 2”
Capacities:
Flats Hard………. 2” x 3/8” x 16” Dia
Flats Easy………. 3” x 5/8” x 16” Dia
Square Bar………. 1-1/8” x 24” Dia
Angle Leg Out……. 1-1/2” x 3/16” x 16” Dia
Angle Leg In…….. 1-1/2” x 3/16” x 22” Dia
Tee Leg Out……… 2” x 16” Dia
Tee Leg In………. 2” x 20” Dia
Channel Leg Out….. 2” x 12” Dia
Channel Leg In…… 2” x 16” Dia
Round Bar……….. 1-1/4” x 24” Dia
Pipe……………. 1-1/2” x 20” Dia
Tubing Round…….. 2-3/8” x 1/16” x 40” Dia
Tubing Square……. 1-1/2” x 1/8” x 40” Dia
Tubing Rectangle…. 2” x 1” x 1/8”
Rolling Speed:……… 10.5 FPM
Work Plane:………… Horizontal
Adjustable Rolls:…… 2-3/8” x 1/16” x 40” Dia
Motor:…………….. 1.15 HP – 220V – 3 Phs
Weight:……………. 450 Lbs
EQUIPPED WITH :
(3) Roll Single Pinch
Mechanical Operated
Manually Adjustable Top Roll
(2) Powered Lower Rolls
Fixed Horizontal Position
Forward & Reverse Rolling
Hardened Shafts
Self Aligning Roller Bearings
Rugged Steel Frame
Knurled Lower Rolls
Foot Pedal Rotation Control
Safety Indicator Lights
Thermal Overload Relay
Dual E-Stop Switches
Integrated Base w/Storage
(2) Multi-Positional Lateral Guides w/Thrust & Rake Angle Settings
Service Tools
